EXT LMEEs are ideal for high warpage BLT applications in TIM1.5/TIM2 applications. For information on our products in the EXT product portfolio, contact us using the form below.
| Property | EXT-510X |
|---|---|
| Thermal Resistance @ BLT (mm²K/W) | 15 @ 150 µm 10 @ 100 µm 5 @ 50 µm 2.5 @ 25 µm 2 @ 20 µm |
| Thermal Conductivity (W/mK) | 10-12 |
| HAST Performance | 96 h
(50°C/95% RH) |
| Thermal Shock Test | 72 cycles (0°C to 125°C) |
| Power Cycling | 10,000+ (ongoing) |
